Radio:
Dual-radio dual-band:
Radio 1: 2.4G 11ax/5G 11ax: 2×2 MIMO;
Radio 2: 5G 11ax: 2×2 MIMO;Protocol:
Concurrent 802.11ax and 802.11a/b/g/n/ac;
BLE 5.0;
Operating Bands:
802.11b/g/n/ac/ax :2.4G ~ 2.4835GHz;
802.11a/n/ac/ax : 5G:5.150~5.350GHz, 5.725~5.850GHz;
(Note: the operating bands varies according to different countries);
Antenna: Built-in directional antenna;
Antenna Loba Orientation:
Internal Directional: 60 degrees total;
Antenna Gain: 9dBi;
Spatial Streams: 4 spatial streams, MU-MIMO;
Max Throughput:
Up to [email protected];
Up to 1.2Gbps@5G;
Up to 2.4Gbps per AP;
2.4G+5G is recommended with 1.775Gbps access rate;
Modulation:
OFDM:BPSK@6/9Mbps,QPSK@12/18Mbps,16-QAM@24Mbps,64-QAM@48/54Mbps;
DSSS:DBPSK@1Mbps,DQPSK@2Mbps,and [email protected]/11Mbps;
MIMO-OFDM:BPSK,QPSK,16QAM,64QAM and 256QAM;
OFDM:BPSK@6/9Mbps,QPSK@12/18Mbps,16-QAM@24Mbps,64-QAM@48/54Mbps;
DSSS:DBPSK@1Mbps,DQPSK@2Mbps,and [email protected]/11Mbps;
MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM and 1024QAM;
Receiver Sensitivity:
11b:-91dBm(1Mbps),-88dBm(5Mbps),-85dBm(11Mbps);
11a/g:-89dBm(6Mbps),-80dBm(24Mbps),-76dBm(36Mbps),-71dBm(54Mbps);
11n:-83dBm@MCS0,-65dBm@MCS7,-83dBm@MCS8,-65dBm@MCS15;
11ac HT20:-83dBm(MCS0), -57dBm(MCS9);
11ac HT40:-79dBm(MCS0), -57dBm(MCS9);
11ac HT80:-76dBm(MCS0), -51dBm(MCS9);
11ax HT80:-76dBm(MCS0), -49dBm(MCS11);
Maximum Transmit Power: 28dBm;
(Note: The actual transmit power varies according to different countries and regions);
Adjustable Power: 1dBm;
Service Ports:
1 10/100/1000Base-T Ethernet uplink port(PoE);
1 SFP port;
Management Port: 1 console port;
Bluetooth: Support switching between Bluetooth serial port and iBeacon;
Power Supply:
Support PoE (802.3af / 802.3at);
Support 44 ~ 57V DC power supply (DC Power adapters should be purchased from third-party vendors separately if needed.);
Power Consumption: <12.95W;
Installation Mode: Wall/pole-mount installation;
IP Rating: IP68;
MTBF: 250,000 hours;
Wi-Fi Alliance:
Wi-Fi CERTIFIED™ a, b, g, n, ac;
Wi-Fi CERTIFIED 6™;
WPA3™-Enterprise, Personal;
Wi-Fi Enhanced Open™;
Wi-Fi Agile Multiband™;
WMM® |
